2.4 GHz 16dBi 120 degree dual polarized mimo sector panel antenna TPE-2400-16D120-2S manufacturer from China Tesswave Communications Equipment Co.,Ltd

2.4 GHz 16dBi 120 degree dual polarized mimo sector panel antenna

Payment Terms:	T/T,L/C,D/P,WU,
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: TPE-2400-16D120-2S

Production Capacity: 5000pcs/month

Type: Outdoor

Frequency Range: 2.4GHz

Polarization: Vertical and horizontal

Means of Transport: Ocean,Land,Air,

Packing: cartons

Brand Name: Tesswave

Gain: 16dBi

Connector: 2*N Female

Freq-MHz: 2400-2500
Gain: 2×16dBi
BW-°: E7 / H120
Polarization: V and H

2.4 GHz 16dBi 120 degree dual polarized mimo sector panel antenna
We are china leading manufacturer, we export antennas to worldwide. please contact us today for a better deal.
website: tesswave.com
email: sales(@)tesswave.com
Tel: +86-757-87666452

Electrical
Model	TPE-2400-16D120-2S
Frequency Range-MHz	2400-2500
Gain	2×16dBi
VSWR	≤1.5
Polarization	Vertical and Horizontal
F/B Ratio-dB	≥25
Isolation-dB	≥28
Horizontal Beamwidth-°(6db)	120
Vertical Beamwidth-°	7
Max power-W	100
Nominal Impedance-Ω	50
Lightning Protection	DC Ground
Mechanical
Connector	2×RP-SMA Female or customized
Antenna Dimension-mm	795×165×65
Enclosure Dimension-mm	205×120×40
Weight-kg	5
Cover Material	PVC
Mast Diameter-mm	Φ40 to 50
Operating temperature-℃	-40~+65
Rated Wind Velocity-m/s	60
